DDR5 32GB 2R*8 5600 NB

This product adopts the latest DDR5 memory technology standard and is designed based on a 2Rx8 dual column memory architecture. It consists of 16 2Gb capacity FBGA packaged DDR5 SDRAM particles, with a total capacity of 32GB. The module supports a high data transmission rate of 5600MT/s, with timing parameters of CL46-46-46 and a working voltage of 1.1V ± 3%. It achieves high-speed and stable signal transmission through a 262 pin SODIMM interface. The product adopts an 8-layer glass fiber PCB board design and integrates high-performance PMIC power management chips, which can accurately regulate the power supply voltage and timing parameters. Support On Die ECC error checking mechanism, effectively improving data reliability. The module is equipped with an SPD chip that complies with JEDEC standards and stores complete configuration information.

Description

High performance: 5600MHz frequency, CL46 timing, improving system operating efficiency.

High reliability: Original factory particles, passed strict quality testing.

Wide compatibility: Supports mainstream Intel/AMD platforms and adapts to various motherboard chipsets.

Environmentally friendly design: Environmentally friendly PCB, compliant with RoHS lead-free standards.

DDR	DDR5
Type	SO-DIMM
Capacity	8GB/16GB/32GB
PCB Color	Green(G)/Black(B)
Organization	1R8/2R8
Operating Frequency	4800MHz/5600MHz/6000MHz
Voltage	1.1V (±0.06V)
PINS	260 pins
Bus Width	64 Bits
PCB height	47.00±4.0 mil
Operating Temperature	0℃~85℃
3µ”Gold Finger	Y
Anti vulcanization	Y
Applications	Laptop/Mini-PC/All-in-One PC/Small-scale Server
CL Timing	Different products vary
Performance	The higher the frequency, the faster the data transmission speed and the better the performance, but the actual performance is still affected by factors such as particle quality, motherboard, CPU, etc
